DZKW-4型電熱恒溫水浴鍋適用于醫療單位、科研、化工、制藥、石油、印染等行業的化驗部門做蒸餾、干燥、濃縮及恒溫加熱化學藥品及生物用品等廣泛用途。本產品由原地礦部唯一指定企業生產,執行行業標準。
1、外殼采用優質冷軋鋼板制成、表面經噴塑工藝處理。
2、工作室與頂蓋圈均用進口不銹鋼板制成,結構設計合理、抗腐蝕性強、造型美觀、操作方便、使用壽命長等優點。
3、溫度控制可選指針式、數字顯示、微電腦控溫儀表、具有控溫精度高、性能穩定、操作簡便等優點。
DZKW-4Thermostatic Water Bath is applicable for labs of medical institutions, research institutes and chemical, pharmaceutical, petroleum, printing and dyeing industries to make distillation, drying, concentration and constant heating of chemical drugs and biological products as well as others. The product is made by the only manufacturer designated by the former Ministry of Geology and Mineral Resources, in compliance with the Industrial standards.
1、The outer shell is constructed of quality cold rolled steel plate and the surface is subject to plastic spraying process treatment.
2、The working chamber and the head cover are made up of imported stainless steel sheet with rational designed structure, strong corrosive resistance, beautiful shape, simple operation, long service life and other advantages.
3、The temperature controls can be selective pointer-type and digital display-type and micro-computer temperature control instruments with high accuracy of temperature control, desirable stability,simple operation and other advantages.
型號規格
Model |
DZKW-4 | ||||||
單孔 | 單二 | 單四 | 單六 | 雙四 | 雙六 | 雙八 | |
功率 Power(W) | 300 | 500 | 1000 | 1500 | 1000 | 1500 | 2000 |
工作電壓 Rated voltage |
220V±10% 50Hz | ||||||
控溫范圍 Controlled temperature |
室溫10
|
||||||
溫度波動度 Temperature |
±
|
||||||
示值誤差 | ±
|
||||||
工作室尺寸 Operation dimensions(mm) |
170×170 ×90 |
320×170 ×90 |
620×170 ×90 |
940×170 ×90 |
320×325 ×90 |
480×325 ×90 |
620×325 ×90 |
外型尺寸 Overall dimensions(mm) |
300×260 ×220 |
490×260 ×200 |
780×260 ×200 |
1080×260 ×200 |
500×400 ×365 |
630×400 ×365 |
800×400 ×365 |
