該機適用于冶金、煤炭、化工、建材、地質、石油等部門的選礦實驗室、科研單位對少量礦物進行精選分離及進行連續浮選、還可用于新機型的研究及機型選擇試驗工作及半工業型試驗。該機采用變頻技術，葉輪無級調速，數字顯示，調整精確，運轉可靠。
The machine is suitable to be used in research institutes and mineral processing labs in metallurgical, coal, chemical, building material, geological, petroleum and other industries for separating , cleaning and continuously floating minor samples as well as new machine type research and selection test and semi-commercial test. It introduces frequency conversion technology, stepless speed governing of impeller and digital display with accurate adjustment and reliable operation.
| 型號規格 Model |
容量 Capa. |
選槽容積 Volume |
葉輪直徑 Impeller diameter |
葉輪轉速 Impeller speed |
給礦粒度 Feed size |
功率 Motor power |
質量 Weight |
| g | L | mm | r/min | mm | w | kg | |
| FJ | 8組16槽 | 1.5、3 5、7 | Φ73、Φ95 Φ120 | ≤2400 | ≤0.5 | 250 | 500 |
| FJ8
|
4組8槽 | 5 | Φ95 | ≤2400 | ≤0.5 | 250 | 250 |
我們要求服務人員時刻關注客戶，及時解決設備問題，確保顧客的利益比一切都重要。
