輥筒式球磨機是一種操作靈活、可靠、設計緊湊的球磨機機型,可方便精確地將實驗結果放大到生產機型,他主要是針對粉碎、研磨、分散、乳化金屬、非金屬、有機、中草藥等粉體進行設計的,特別適合實驗室研究使用,其工作原理是利用磨料與試料在研磨罐內高速翻滾,對物料產生強力剪切、沖擊、碾壓達到粉碎、研磨、分散、乳化物料的目的。能很好的實現各種工藝參數要求,模擬生產中的各項指標,同時由于其小批量、低功耗、低價位的優點,是學校、研究單位、公司是進行粉碎工藝、新材料、涂料研究的****設備。廣泛應用于陶瓷、材料、化工、礦業、水泥、非金屬工業等領域。
Rollers Drums Ball Mill is a type of machine that features flexible operation, reliability, and compact design as well as conveniently and accurately applies the experimental results to production. It is designed mainly to crush, grind, separate and emulsify powder of metal, nonmetal, organic, Chinese herbal medicine, etc. It is especially suitable to be used for laboratory research. Its working principle is: It crushes, grinds, separates, and emulsifies materials through violent shearing, impact, and crushing of materials when the grinding materials and sample materials turn over at high speeds in the grinding tank. It satisfactorily meets the requirements of various technological parameters, and simulates various production indexes. Besides, it enjoys advantages including small batch, low power consumption, and low price. It is the preferred device for schools, research units, and companies to engage in the research into crushing technology, new materials and coating. Such equipment is widely applied in fields such as ceramics, materials, chemicals, mining, cement, and non-metal industry.
規格型號 | GQM-1 | GQM-2 | GQM-3 | GQM-5 | GQM-10 | GQM-15 | ||||
研磨有效體積 | L | 1 | 2 | 3 | 5 | 10 | 15 | |||
功率 | W | 370 | 370 | 370 | 370 | 750 | 750 | |||
電壓 | V | 220 | 220 | 220 | 220 | 220 | 220 | |||
負載 | kg | 8 | 10 | 20 | 40 | |||||
調速方式 | 無級調速 | 無級調速 | 無級調速 | 無級調速 | 變頻調速 | 變頻調速 | ||||
****轉速 | r/min | 200 | 200 | 200 | 200 | 250 | 250 | |||
外形尺寸 | mm | 640×320×200 | 660×33 ×200 |
680×350 ×200 |
720×370 ×200 |
785×420 ×250 |
825×425 ×250 |
