該機是綜合國內外破碎縮分設備的性能及優點研制而成的新型多功能設備,其****的優點是,可對各種不同硬度的物料進行快速破碎、混樣、縮分,縮分比可調,進料粒度大,出料粒度均勻,大小可調,不受樣料含水量大的影響,破碎效果好,不堵料,不失原料水份,并可代替手工完成多個制樣步驟,免除了人工操作誤差,密封性能好,無粉塵污染,操作、維修十分安全方便。適用于冶金、煤炭、電力、礦山、化工、環保、科研等部門,屬目前國內新型、領先的產品。本產品由原地礦部唯一指定企業生產,執行行業標準。
Laboratory Crushing Splitter is a new multi-function device developed with integration of performances and advantages of crushing and reduction units at home and abroad with the most important advantages being speedy crushing, blending and reduction of the materials with different hardness, adjustable reduction ratio, large feed size, uniform output size, adjustable particle size, no effect of water content in sample, good crushing effect, no material blocking , no loss of moisture in material, accomplishing procedures of preparing several samples instead of manual operation to avoid errors caused by manual operation, good sealing performance, no dust pollutions and convenient operation and maintenance . It is suitable to be applied in metallurgical, coal, electric power, mine, chemical, environmental protection, scientific research and other sectors and considered as a new and leading Product. The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Resources, in compliance with the Industrial standards.
XPF100×125A型試樣連續破碎縮分機 Crushing splitter |
CGP60×100型破碎縮分聯合制樣機 Crushing splitter |
||||
---|---|---|---|---|---|
給料粒度 Feed size |
mm | ≤80 | 進料粒度 Feed size |
mm | ≤25 |
產物粒度Opening size | mm | ≤2 | 產物粒度Opening size | mm | 1-5 |
試樣重量縮分比調節范圍 | 1/2 1/4 1/8 1/16 (可調) | 試樣重量縮分比調節范圍 | 1/2、1/4、1/8 | ||
功率Power | % | 4 | 功率Power | kw | 1.5 |
處理能力Capacity. | kg/h | 60~130 | 處理能力Capacity. | kg/h | ≤30 |
外形尺寸 Overall dimensions | kw | 1380×720×1550 | 外形尺寸 Overall dimensions | mm | 850×550×1065 |
重量 Weight | kg | 800 | 機重Weight | kg | 480 |
LMZ型連續進出料制樣機crushing splitter | ||||||
型號 Model |
一次制樣數 Cups numbe |
裝料粒度 Feed size |
裝料重量 Capacity |
粉碎時間 Crusher time |
出料粒度 Output size |
功率 Power |
---|---|---|---|---|---|---|
(個) | mm | g/每缽 | min | (目) | kw | |
LMZ-120 | 1 | <15 | 連續進出料 | 120g/s | ≤250 | 1.1 |
LMZ-100 | 1 | <15 | 連續進出料 | 500g/min | ≤250 | 1.1 |
